2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production

2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production

10-layer co-extrusion Blow Molding Equipment

2000L large-capacity IBC Blow Molding Machine

Intelligent control system Water Tank Blow Molding Machine

Place of Origin:

CHINA

Brand Name:

HUAYU

Certification:

ISO9001 CE

Model Number:

HYBM-2000-10

Chat Now
Request A Quote
2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production
2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production 2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production 2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production 2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production
Product Details
Voltage:
Pending
Total Power:
570kw
Average Power:
320kw
Machine Dimension (L*W*H):
12.6*11*7.6
Productivity:
10-24pcs/h
Screw Diameter:
100*6mm
Screw L/D Ratio:
28：1
Accumulator Capacity:
60kg
Maximum Air Pressure:
0.8Mpa
Air Consumption:
2.3m3/min
Clamping Force:
1800KN
Highlight:

10-layer co-extrusion Blow Molding Equipment

,

2000L large-capacity IBC Blow Molding Machine

,

Intelligent control system Water Tank Blow Molding Machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
340000 USD
Packaging Details
be disassembled into many parts for container transportation
Delivery Time
4 MONTHS
Payment Terms
T/T,L/C
Supply Ability
1SET 120DAYS
RELATED PRODUCTS
CONTACT US
86-152-6568-7399
padraic@huayumachine.cn
86-0536-770-9997
Chat Now
Product Description
2000L 10-Layer Water Tank Blow Molding Equipment: Durability Redefined
Core Advantages
  • 10-layer co-extrusion structure enables precise layer ratio control, providing water tanks with excellent barrier properties, corrosion resistance, and pressure resistance for long-term liquid storage
  • 2000L large-capacity molding integrates high-efficiency clamping and blow molding systems, supporting one-step molding to reduce secondary processing and production costs
  • Intelligent control system with PLC touch screen operation interface enables real-time monitoring of temperature, pressure, and molding speed for consistent product quality
  • Energy-saving design featuring variable frequency speed regulation and heat recovery technology reduces energy consumption by 15% and increases daily output by 20%
  • Durable mechanical configuration with heavy-duty frame and high-strength mold clamping components ensures stable operation under high-load conditions with 30% extended service life
  • Flexible customization capability supports layer thickness adjustment and mold replacement for various 2000L water tank shapes and material formulas
  • Environmental compliance with closed feeding and exhaust treatment system meeting international standards and producing food-grade certified tanks
Hydraulic System Specifications
Main Oil Tank Capacity 1200L Servo motor, less energy consumption, high efficiency, low noise
Main Oil Pump Gear Pump 160CC
Main Oil Pump Motor 45kw
Servo Oil Tank Capacity 200L
Servo Oil Pump Model Plunger Pump 22
Servo Oil Pump Motor 7.5kw
Electronic System Specifications
Main Operation Panel Touch Screen 12"
Control System PLC
Thickness Control Points 200 Points
Temperature Control PLC Module
2000L 10-Layer Water Tank Blow Molding Machine with Intelligent Control System for Large-Capacity Production 0
