Name: 2000L Single-Layer Blow Molding Machine
Brand: Weifang Huayu Plastic Machinery Co., Ltd.
SKU: HYBM-2000L-1
Price: 410,090.00 USD
Availability: InStock

Home > Products > IBC Blow Moulding Machine >

2000L Single-Layer Blow Molding Machine

2000L single-layer blow molding machine

IBC blow molding machine with warranty

single-layer blow molding machine for IBC

Place of Origin:

China

Brand Name:

Huayu

Certification:

CE,ISO9001

Model Number:

HYBM-2000L-1

Chat Now

Request A Quote

Product Details

Temperature Control:

Modular Temperature Control

Mould Material:

Aluminum

Material:

Plastic

Heatingpower:

18 KW

Color:

Customizable

Maxcontainercapacity:

2000 Liters

Thickness Controller:

MOOG

Cleaning Method:

Easy Cleaning

Feeding Motor:

2.2kw

Cycletime:

30 Seconds

Screw Material:

38 CrMoAIA, Nitriding

Max Parison Diameter:

150-300 Mm

Screw Diameter:

80mm*8

Highlight:

2000L single-layer blow molding machine

IBC blow molding machine with warranty

single-layer blow molding machine for IBC

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiate

Packaging Details

by container

Delivery Time

4 months

Payment Terms

L/C,T/T

Supply Ability

4 sets per month

RELATED PRODUCTS

86-152-6568-7399

padraic@huayumachine.cn

86-0536-770-9997

Chat Now

Product Description

The 2000L single-layer blow molding machine is a classic large-capacity single-material extrusion blow molding equipment. Adopting single extruder integrated molding technology, it is specially used for mass production of 2000L large ordinary plastic storage containers. With simple structure, stable operation and high cost performance, it is the mainstream equipment for civil and conventional industrial large container production.

The equipment uses single HDPE material one-time extrusion molding, with simple and reliable production process. The whole machine has fewer wearing parts, low failure rate and convenient daily maintenance. The optimized large-diameter screw ensures uniform plasticization and stable parison extrusion, effectively solving the problems of uneven wall thickness and insufficient filling of super-large containers. The fully automatic production process including clamping, blowing, cooling and demolding realizes continuous and efficient production.

Limited by single-layer single-material structure, the equipment has no special barrier and anti-corrosion function, so it is only suitable for storing neutral water, ordinary agricultural solutions and non-corrosive industrial materials. Its advantages lie in low equipment investment, low energy consumption and high production efficiency, which can meet the large-scale production needs of ordinary large-capacity containers and create high economic benefits for enterprises.

Core technical parameters are shown in the table below:

Technical Item	Parameter Value	Unit
Maximum Product Volume	2000	L
Screw Specification	130	mm
Plasticizing Capacity	600-700	kg/h
Dry Cycle Efficiency	140	Pc/h
Main Motor Power	110	kW

This single-layer equipment is widely used in civil water storage, agricultural irrigation and general industrial storage scenarios. With mature technology and stable performance, it has become the most cost-effective choice for large-capacity ordinary container mass production.
