Name: 2000L Three-Layer Co-Extrusion Blow Molding Machine
Brand: Weifang Huayu Plastic Machinery Co., Ltd.
SKU: HYBM-2000L-3
Price: 410,090.00 USD
Availability: InStock

Home > Products > IBC Blow Moulding Machine >

2000L Three-Layer Co-Extrusion Blow Molding Machine

2000L IBC blow molding machine

three-layer co-extrusion blow molding machine

industrial blow molding machine with warranty

Place of Origin:

China

Brand Name:

Huayu

Certification:

CE,ISO9001

Model Number:

HYBM-2000L-3

Chat Now

Request A Quote

Product Details

Die Head Heating:

90KW

After Sales:

OVERSEAS SERVICE

Max Parison Diameter:

150-300 Mm

Controller:

PLC+Touch Screen

Total Weight:

49T

Cooling Water Consumption:

3m3

Layer:

1layer

Average Aonsumption:

280KW

Parison:

MOOG 200point

Screw Material:

38CrMoAlA，Nitriding

Temperature Control:

Modular Temperature Control

Feeder Type:

Vacuum Feeder

Bucket Thickness:

Not Very Thick

Accumulator Capacity:

12kg

Material:

Plastic

Highlight:

2000L IBC blow molding machine

three-layer co-extrusion blow molding machine

industrial blow molding machine with warranty

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiate

Packaging Details

by container

Delivery Time

4 months

Payment Terms

L/C,T/T

Supply Ability

4 sets per month

RELATED PRODUCTS

86-152-6568-7399

padraic@huayumachine.cn

86-0536-770-9997

Chat Now

Product Description

The 2000L three-layer co-extrusion blow molding machine is a cost-effective mid-end multi-layer equipment for large-capacity containers. It adopts three-extruder co-extrusion technology to form outer protection, middle barrier and inner sanitary three-layer composite structure. It solves the insufficient barrier performance of double-layer products and avoids the high cost of high-grade multi-layer equipment, suitable for medium and high-standard large-capacity container production.

Each layer has clear functional division. The outer high-toughness layer improves mechanical strength and weather resistance, resisting external impact and ultraviolet aging. The middle independent barrier layer effectively blocks oxygen and moisture penetration, preventing stored materials from deteriorating and volatilizing. The inner food-grade anti-corrosion layer ensures the safety of stored liquid materials. The three-layer structure greatly improves the comprehensive barrier performance of large containers with controllable production costs.

Equipped with precision three-layer die head and synchronous control system, the machine realizes accurate layer ratio and uniform wall thickness molding for 2000L super-large containers. The optimized plasticization system adapts to synchronous processing of multiple resins with stable material performance. The fully automatic production process is efficient and stable, with low failure rate and simple maintenance, supporting long-term stable mass production.

Core technical parameters are shown in the table below:

Technical Item	Parameter Value	Unit
Maximum Product Volume	2000	L
Screw Specification	100*3	mm
Total Plasticizing Capacity	550-650	kg/h
Dry Cycle Efficiency	130	Pc/h
Single Extruder Power	45	kW

This 2000L three-layer equipment is widely used in food-grade liquid storage, medium-corrosion chemical containers and large environmental protection water tanks. With balanced performance and cost advantages, it has become the most popular mid-to-high-end model in the large-capacity multi-layer blow molding market.
